Colorlight S2 LED Display Sender Card Features:

1) Support DVI signal input
2) Support audio input, synchronous transmission through the network cable
3) Maximum input resolution: 1920*1200 pixels.
4) Loading capacity: 1.31 million pixels. Max in Width: 2560 pixels, Max in Height: 2560 pixels.

$105.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites

1/1

Description
Shipping Policy
Why Us

Colorlight S2 LED Display Sender Card Features:

1) Support DVI signal input
2) Support audio input, synchronous transmission through the network cable
3) Maximum input resolution: 1920*1200 pixels.
4) Loading capacity: 1.31 million pixels. Max in Width: 2560 pixels, Max in Height: 2560 pixels.
5) 2 Gigabit Ethernet port outputs support screen arbitrary splicing
6) Dual USB ports for high speed configuration and easy cascading
7)Improved grayscale performance at low brightness
8) Equip with 1X PCI-E interface, more versatile
9) Wide working voltage with DC 3.8~12V
10) Compatible with all series of Colorlight receiving cards

Colorlight S2 LED Display Sender Card Parameter:

Video source interfaces
Type	DVI
Receiving Resolution	1920*1080 in max
Frame Rate	Standard 60Hz, and auto adjustment
Gigabit Ethernet Outputs
Quantity	2 ports
Net Port Control Area	Each net port is 1280512 pixels (or equivalent area). 2 net ports are 12801024 pixels (or equivalent area) Single card max width up to 2560 pixels, and 2560 pixels in height
Transmission distance	CAT5≤140M；CAT6≤170M；Optical fiber: No limitation
Splicing	Arbitrary
Transmission Mode	Frame mode (Gigabit Ethernet) with CRC
Connecting Device
Receiving card	All series
Peripheral Device	Multifunction cards, fiber optic transceivers, Gigabit switches
Parameters
Size	140*105 mm
Input Voltage	DC 3.8V-12V
Power Consumption	6W
Weight	100g
External Interface
Configuration Port	USB
Real-time Configuration	Support
Brightness and Chromaticity Adjustment	support
Smart Detection System	DVI interface
Real-time Clock	Support
More Functions
Multi Screen Control	Multiple screens with different sizes can be controlled at one time
Background Playing	Support (Extended mode)
Audio Transmission	Support
BER Detection	Net cable quality and malfunction detection
